型号Model |
PZ2020G |
PZ3030G |
PZ4040G |
PZ5050G |
|||
机床型式Type of the machine |
龙门移动式(X轴导轨丝杠上置) Movable gantry type(the guide screw of axis on top side) |
||||||
加工能力(mm) Processing capacity
|
加工范围(长×宽) Processing range(L*X) |
2000*2000 |
3000×3000 |
4000×4000 |
5000×5000 |
||
主轴下端面到工作台面距离 distance between the bottom of the spindle to work table |
230-730 |
||||||
大钻孔直径 Max drilling depth
|
Φ50 |
Φ50 |
Φ50 |
Φ50 |
|||
大钻孔深度 Max drilling depth |
250mm |
||||||
轻铣 Milling |
Φ100mm刀盘、深2mm(材质Q345) Φ100mmcutter head, depth 2mm (material Q345) |
||||||
钻削动力头 Drilling power head
|
动力头型式 Type of power head
|
滑枕式伺服控制动力头 Ram type servo control power head |
|||||
数量 Quantity |
1 |
1或2 |
2 |
2 |
|||
主轴端连接型式 Type of connection mold of spindle |
BT50锥孔 Bt50 cutter head |
||||||
刀柄装夹型式 Type of clamp |
碟簧拉杆装置(液压打刀) Pull rod butterfly spring device (hydraulic marking) |
||||||
主轴转速 (r/min) Rotating speed of spindle |
30-2400 |
||||||
主轴电机功率(kw) Motor power of spindle |
22 |
22或22*2 |
|||||
定位精度(mm) Positioning accuracy
|
X、Y、Z轴(mm) axis |
≤0.04 |
|||||
重复定位精(mm) Re-positioning accuracy |
≤0.03 |
||||||
主轴与工作台的垂直度(mm) verticality of spindle to work table |
≤0.03/300 |
||||||
主轴端面及侧面跳动度(mm) Run out of the bottom of spindle and the side of spindle |
≤0.02 |
||||||
机床总重量(t) Total weight of the machine |
24 |
35 |
56 |
70 |
|||
机床外形尺寸(长*宽*高)(mm) Outline dimension (L*W*H) |
4600*4200*3900 |
5800*5520*3900 |
7600*6540*3900 |
9200*8500*4300 |
